PISTON SEALS

Artic Seals designs, develops and manufactures a range of Hydraulic and Pneumatic Piston Seals for cylinders, actuators and other pressure related equipment in both double acting and single acting configurations. The function of a piston seal is to separate and contain pressure acting on one or both sides of a piston and preventing leakage between the full bore and anulus side of the cylinder. The resulting action of retaining this pressure translates in to force and subsequently stroke movement of the piston within the cylinder.

Artic Piston Seals are available in a wide range of styles, materials and dimensions for a diverse range of applications; high and low pressures up to 600 bar, temperatures (-50°C to +230°C), low friction, high speed compact designs and composite materials. Artic Piston Seals are available in a wide range of metric and imperial sizes that comply with most international mounting standards including ISO 6020, ISO 5597 and ISO 7425-2. Materials include TPU, TPE, PTFE, NBR and High-Performance Engineered Plastics.

Our Ref Application Temperature Pressure Bar Speed m/s Material
Image for PISTON SEALS RPS Hydraulic-35?C to +100?C<400 Bar<0.5 m/sTPU - Polyurethane
Image for PISTON SEALS PSA Hydraulic-35?C to +100?C<400 Bar<0.5 m/sTPU - Polyurethane
Image for PISTON SEALS PAE Hydraulic-35?C to +100?C<400 Bar<0.5 m/sTPU - Polyurethane
POM - Acetalic Resin
Image for PISTON SEALS PSH+RR Hydraulic-35?C to +100?C<400 Bar<0.5 m/sTPU - Polyurethane
POM - Acetalic Resin
Image for PISTON SEALS PSO Hydraulic-30?C to +100?C<250 to <500 Bar

depending on material

<0.5 m/sTPU - Polyurethane
NBR - Nitrile Rubber
Image for PISTON SEALS PSQ Hydraulic-30?C to +100?C<250 to <500 Bar

depending on material

<0.5 m/sTPU - Polyurethane
NBR - Nitrile Rubber
Image for PISTON SEALS PSN Hydraulic/
Pneumatic
-30?C to +110?C<250 Bar<4 m/sTechnoploymer
NBR - Nitrile
Image for PISTON SEALS TPD Hydraulic-30?C to +120?C<600 Bar15 m/sPTFE Bronze
NBR - Nitrile Rubber or
FPM Rubber
Image for PISTON SEALS PSZ Hydraulic-30?C to +110?C<600 Bar1 m/sPA66 & NBR-Nitrile Rubber
Image for PISTON SEALS PHP Hydraulic-30?C to + 100?<600 Bar<1.5 m/sTPU - Polyurethane
POM - Acetalic Resin
NBR - Nitrile Rubber
Image for PISTON SEALS KDSA Hydraulic-30?C to +100?C<300 Bar<0.5 m/sTPU - Polyurethane
NBR - Nitrile Rubber
TPE - Thermoplastic Elastomer
Image for PISTON SEALS KDSB Hydraulic-30?C to +100?C<300 Bar<0.5 m/sTPU - Polyurethane
NBR - Nitrile Rubber
TPE - Thermoplastic Elastomer
Image for PISTON SEALS KDSI Hydraulic-30?C to 100?C<300 Bar<0.5 m/sTPU - Polyurethane
NBR - Nitrile Rubber
TPE - Thermoplastic Elastomer
Image for PISTON SEALS KDSP Hydraulic-30?C to +100?C<300 Bar<0.5 m/sTPU - Polyurethane
POM - Acetalic Resin
Image for PISTON SEALS KDAE Hydraulic-30?C to +100?C<400 Bar<0.5 m/sTPU - Polyurethane
TPE - Thermoplastic Elastomer
Image for PISTON SEALS KDSAE Hydraulic-30?C to +100?C<0.5 m/sTPU - Polyurethane
NBR - Nitrile Rubber
TPE - Thermoplastic Elastomer
Image for PISTON SEALS PSP Pneumatic-30?C to +90?C<20 Bar<1 m/sTPU - Polyurethane
Image for PISTON SEALS MPS Pneumatic-30?C to +90?C<20 Bar<1 m/sTPU - Polyurethane
Image for PISTON SEALS MPS/2 Pneumatic-30?C to +90?C<20 Bar<1 m/sTPU - Polyurethane
Image for PISTON SEALS MPM Pneumatic-40?C to +90?C<20 Bar<1 m/sPOM - Acetalic Resin
NBR - Nitrile Rubber
TPU - Polyurethane
Image for PISTON SEALS SPS Pneumatic
Pneumatic
TPU: -40?C to +90?C NBR: -30?C to +100?C

<20 Bar

<12 Bar

<1 m/s
<1 m/s

TPU - Polyurethane or

SPS/N-NBR Nitrile Rubber

Image for PISTON SEALS MPP Pneumatic-30?C to +100?C<20 Bar<1 m/sNBR - Nitrile Rubber
Steel
Image for PISTON SEALS CUP Pneumatic-40?C to +90?C0.5 to 10 Bar -TPU - Polyurethane
Image for PISTON SEALS PLF Pneumatic-40?C to +90?C<20 Bar<1 m/sTPU - Polyurethane
Image for PISTON SEALS PSI -35?C to +100?CTPU - Polyurethane
NBR - Nitrile Rubber
